Great Magtech (Xiamen) Electric Co., Ltd yog ib qho ntawm feem txhim khu kev qha manufacturers thiab lwm tus neeg ntawm ntsug cnc machining chaw gmv-966 nyob rau hauv Suav teb. Peb sov siab txais tos koj mus yuav cov khoom zoo ntsug cnc machining chaw gmv-966 los ntawm peb lub hoobkas. Tiv tauj peb kom paub meej ntxiv.
Vertical CNC Machining Centers Description
Vertical machining centers muaj peev xwm ua tiav ntsug milling rau precision manufacturers ua hauj lwm uas koom nrog siab -ceev machining, nyuaj- rau- cov ntaub ntawv tshuab, thiab hnyav- lub luag haujlwm txiav.
Peb cov kev cai tsim koj qhov kev daws teeb meem VMC nrog lub ntiaj teb- cov khoom tsim tsim hauv chav kawm los muab kev ceev thiab kev ruaj ntseg thaum tseem xa qhov raug thiab raug-txhua yam tsim los tsav koj cov txiaj ntsig thiab ROI.
Vertical Ncej Tshuab Tus yam ntxwv
1. Peb-axis txais Japanese THKΦ40-C3 qib ntsia hlau, peb-axis txais NSK thawj cov kabmob (3062), 3+2 hom, kev kho ua ntej tensioning los tiv thaiv thermal hloov chaw.
2. BBT40 sab nraud txoj kab uas hla 150mm siab rigidity 10000rpm luv lub qhov ntswg ntxaiv. Nws txais 5 bearings, txheem spindle coolant nozzles, thiab xaiv HSK-63 hluav taws xob ntxaiv.
3. Cov lus ua haujlwm 1020 * 570 mm
4. Peb -axis travel X:900/Y:570/Z:680. Qhov tshwj xeeb kev teeb tsa txoj haujlwm ntawm Optical Linear Scales tuaj yeem nruab nrog cov roj hollow -cov khoom txias txias.
5. Optical Linear Scales. Yeem Heidenhain, Fagor optical linear scales, raug ± 5um, los xyuas kom meej qhov chaw ntawm lub tshuab cuab yeej.
6. Nws nruab Japanese THK los yog German Rexroth linear guideway, linear guideway dav txog li 45mm.
7. Kem ob - txheej caj npab qauv, zoo rigidity.
8. Cov txheej txheem huab cua Counter Balance System ua haujlwm ruaj khov dua.
Parameters
| Qauv | Spec | Chav tsev | HWV-966 |
| Mus ncig | X/Y/Z | mm | 900/600/600 |
Spindle Nose rau Worktable | mm | 120-720 | |
Spindle Center rau Kem | mm | 610 | |
| Lub rooj ua haujlwm | Qhov Loj (L * W) | mm | 1020*570 |
Max. Qhov hnyav ntawm lub rooj | kg | 800 | |
T-Qhov | mm | 5-18×90 | |
| Spindle | Spindle Taper | mm | BBT40 |
Ceev | rpm ua | 10000 | |
Hom kis kab mob | BLET | ||
| Feedrate | X/Y/Z Rapid Feedrate | m/min | 36/36/36 |
Txiav FeedRate | m/min | 10000 | |
| Tool Changer (Yeem) | Tool Hloov Mood | Caj npab | |
Specification | hom | BBT | |
Tool Storage Capacity | cuab yeej | 24 | |
| Lub cev muaj zog | Spindle | kws | II 8/12000 |
3-Axis Servo Tsav | kws | iSC 12/3000/ iSC 12/3000/ iSB22/3000 | |
Lub tshuab nqus dej twj tso kua mis | m/h-m | 4-60 | |
| Yuav tsum muaj hwj chim | Kev xav tau hluav taws xob | kva | 20 |
Kev xav tau cua txias | Kg / cm² | 6^8 | |
| Kev ntsuas | L*W*H | mm | 2530*2350*2559 |
Qhov hnyav | t | 6 |
Standard Accessories
Ib nrab-Cov neeg saib xyuas | Cua phom | Neeg kho tshuab roj coolant separator | Spindle roj Coolant |
Nws pib Lubrication System | Rigid tapper | Swiveling Control Box | Nws pib fais fab tuag |
Volumetric Hom Tsis Siv Neeg lubricator | Leveling Bolts thiab Leveling Thaiv | Tsawg Zog ua haujlwm lub teeb | Tool Box |
Handwheel | Thaum tshav kub kub Exchanger rau Electric txee | Hloov pauv | Phau ntawv ua haujlwm |
RS 232 code |
Kev xaiv
Spindle RPM | ZF Iav lub thawv lossis Cov iav puv | Spindle Taper (HSK/ISO/CAT/BT) | Tsis siv neeg hloov cuab yeej |
CTS | Tswj kev xaiv (SINUMERIK 840D) | Extended Lub taub hau |
